Fiber optic pigtails provide a fast way to make communication devices in the field. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet your most stringent mechanical and performance specifications.
Application
• Telecommunications
• CATV, LAN, MAN, WAN, Test &Measurement
• Military industry
• Medical
Features
• Low insertion loss and back reflection loss
• Ferrule end surface pre-domed
• Excellent mechanical endurance
• Good in repeatability
• Good in exchange
Product Specification
Connector A | ST | Connector B | Unterminated |
Fiber Mode | 9/125μm | Fiber Count | Simplex |
Fiber Grade | G.652.D/G.657A1/G.657A2 | Minimum Bend Radius | 30 mm |
Polish Type | UPC/APC | Cable Diameter | 0.9/2/3mm |
Cable Jacket | PVC/LSZH Jacket | Color | Yellow/White/Bare |
Wavelength | 1310 nm/1550 nm | Durability | >1000 Times |
Insertion Loss | ≤0.3/0.15/0.2 dB | Interchangeability | ≤0.2 dB |
Return Loss | ≥50/55 dB | Vibration | ≤0.2 dB |
Operating Temperature | -40~75°C | Storage Temperature | -45~85°C |
