Home ／ Fiber Optic Cables ／ Indoor Cable ／ Single Armored Fiber optical Cable for Indoor
  • Single Armored Fiber optical Cable for Indoor
    Single Armored Fiber optical Cable for Indoor
    Single Armored Fiber optical Cable for Indoor
    Single Armored Fiber optical Cable for Indoor
    ❤ Add to collection

  • Single Armored Fiber optical Cable for Indoor

    The price is the price of 1000 meter, increase the order quantity according to the length you need.

    • U.S.＄123.10-153.80
      U.S.＄0.00
      U.S.＄123.10-153.80

    • Satisfaction：

      Sales： 0

      Review： 0

    Weight：0.00KG
    • Quantity：
    • (Inventory: 1199988)
Product parameters
    Description

    The price is the price of 1000 meter, increase the order quantity according to the length you need.

    Application
    • Used in pigtails and patch cords;
    • Used in optical connections in optical communication equipment rooms and optical distribution frames;
    • Used in optical connections in optical apparatus and equipments.

    Features
    • Good mechanical and environmental characteristics;
    • Flame retardant characteristics meets the requirements of relevant standards;
    • The mechanical characteristics meet the requirements of relevant standards;
    • Soft, flexible, easy to splice, and with big capacity data transmission;
    • Meet various requirements of market and clients.

    Product Specification

    Fiber style  Unit SM SM MM MM MM
    G652 G652D 50/125 62.5/125 OM3-300
     condition  nm 1310/1550 1310/1550 850/1300 850/1300 850/1300
     attenuation dB/km ≤ ≤ ≤ ≤3.0/1.0 ≤3.0/1.0
    0.36/0.23 0.34/0.22 3.0/1.0 ---- ----
     Dispresion 1550nm Ps/(nm*km) ---- ≤18 ---- ---- Dispresion
    1625nm Ps/(nm*km) ---- ≤22 ---- ---- 　
     Bandwith 850nm MHZ.KM ---- ---- ≧400  ≧160  Bandwith
    1300nm MHZ.KM ---- ---- ≧800  ≧500 　
     Zero dispersion wavelength nm 1300-1324 ≧1302, ---- ---- ≧ 1295,
    ≤1322 　 　 ≤1320
     Zero dispresion slope nm ≤0.092 ≤0.091 ---- ---- ----
     PMD Maximum Individual Fibr ≤0.2 ≤0.2 ---- ---- ≤0.11
     PMD Design Link Value Ps(nm2*km) ≤0.12 ≤0.08 ---- ---- ----
     Fibre cutoff wavelength λc nm ≧ 1180, ≧1180, ---- ---- ----
    ≤1330 ≤1330 　 　 　
     Cable sutoff wavelength λcc nm ≤1260 ≤1260 ---- ---- ----
     MFD 1310nm um 9.2+/-0.4 9.2+/-0.4 ---- ---- ----
    1550nm um 10.4+/-0.8 10.4+/-0.8 ---- ---- ----
     Numerical 　 ---- ---- 0.200+/ 0.275+/-0. 0.200+/-0
     Aperture(NA) 　 　 　 -0.015 15 0.015
     Step(mean of bidirectional measurement) dB ≤0.05 ≤0.05 ≤0.10 ≤0.10 ≤0.10
     Irregularities over fiber length and point dB ≤0.05 ≤0.05 ≤0.10 ≤0.10 ≤0.10
